E710 15AMP VOLTAGE CONVERTER 24V - 12V

Specification:

• PART NO: E710 – MOD1
• TYPE: SWITCH MODE STEP DOWN VOLTAGE CONVERTER
• RATING: 15 AMP
• MAX CONTINUOUS O/P CURRENT: 15 AMP
• PEAK OUTPUT CURRENT: 20 AMP
• INPUT VOLTAGE: 18 – 30V DC
• OUTPUT VOLTAGE: 13.5V DC
• OVERLOAD PROTECTION: YES
• OUTPUT PROTECTED: YES
• POLARITY PROTECTED: YES
• OPERATING TEMPERATURE: - 40 TO + 70 DEG.C
• HIGH TEMP PROTECTED: YES
• SHORT CIRCUIT PROTECTION: YES
• OVER VOLTAGE PROTECTION: YES
• EFFICIENCY: > 90%
• LOAD REGULATION: 0.3V
• DIMENSIONS: 155mm X 70mm X 53mm
• FIXING CENTRES: 138mm X 40mm (4 HOLE FIXING)
• HOLE SIZE: 4.5mm
• WEIGHT: 447g
• CONSTRUCTION: ANODISED COOLING PROFILE

For O.E.M. Customers, Leads can be terminated to suit your requirements

This Converter has been designed using a building block system to obtain the power needed

to suit your requirements
