E1242 12A 12V-12V Split Charger (12.5V Turn On)

E1242 12AMP SPLIT CHARGER 12V - 12V (12.5V Turn On)


This Unit has a Pink Control Wire which is wired directly to the +ve Connection of the 12V Cranking (Donor) Battery. The Pink Control Wire senses the 12V Cranking (Donor) Battery Voltage and switches the Split Charger on only when the 12V Cranking (Donor) Battery is being charged.

Unlike Relay or Diode Split Chargers this Unit automatically controls the maximum charge into the 12V Leisure (Recipient) Battery preventing it from becoming over-charged / damaged and prevents the 12V Cranking Battery (Donor Battery) from becoming flat / exhausted.

For O.E.M. Customers, Leads can be terminated to suit your requirements

This Battery Charger has been designed

using a building block system

to obtain the power needed

to suit your requirements

Also available from this range:

24A  12V - 12V Split Charger (see E1243)

36A  12V - 12V Split Charger - ask for details

48A  12V - 12V Split Charger - ask for details

60A  12V - 12V Split Charger - ask for details

72A  12V - 12V Split Charger - ask for details

Please contact us if you require a higher current rating than those shown
