E741 24V BATTERY SAVER WITH WARNING
Specification
Specification
This unit is intended to overcome the problem of drivers leaving Vehicle Headlights on whilst the Engine is stationary.
Once the Ignition Switch is turned off the timer commences operation.
If the Ignition supply is not restored within 90 seconds a Buzzer sounds a 10 second warning, the supply to the Lighting Switch is then opened until the Engine is switched On
DESCRIPTION
E741
SUPPLY VOLTAGE (Vcc)
18 TO 30V DC
SUPPLY CURRENT*
Vcc = 24V: < 30mA
OUTPUT SWITCHING CURRENT
10A
TIME DELAY PERIOD
IGNITION OFF UNTIL WARNING OUTPUT ON: 90 ± 9 SECONDS
TIME WARNING PERIOD
WARNING OUTPUT ON UNTIL LIGHTS OFF: 9 ± 1 SECONDS
WARNING OUTPUT (PIN 2)
Vcc = 24V: 250mA
RESET TIME
< 500ms
OPERATING TEMPERATURE
- 30 TO + 70°C
CASE STYLE
DIN CASE & VERTICAL BRACKET
DIMENSIONS
94mm X 61mm X 36mm INCLUDING BRACKET
WEIGHT
84g
FIXING
1 POINT FIXING – 5mm HOLE
*Maximum current consumption when the lighting switch is on and the unit has switched the headlights off.
