PART NO

E791

TYPE

SWITCH MODE STEP DOWN
BATTERY CHARGER

CHARGING CURRENT

60 AMP

INPUT VOLTAGE

18 – 30V DC

OUTPUT VOLTAGE

14V DC

OVERLOAD PROTECTION

YES

POLARITY PROTECTED

EXTERNAL FUSE

HIGH TEMP PROTECTED

YES

SHORT CIRCUIT PROTECTION

YES

EFFICIENCY

> 90%

DIMENSIONS

380mm X 248mm X 55mm

FIXING CENTRES

361mm X 229mm (4 HOLE FIXING)

HOLE SIZE

6mm

WEIGHT

3578g

CONSTRUCTION

4 X E770-MOD3 15A CHARGER MOUNTED ON A SINGLE ALUMINIUM PLATE

E791 60AMP BATTERY CHARGER 24V - 12V

Specification

This 60A Battery Charger =
4 X 15A Battery Chargers wired in parallel
to form a single 60A module
